Audio DAC
Audio DAC
Product number | Classification | working voltage | Package specification | Product description | Product application | LDO | Reset time | Output mode | Response time | Standby power | ADC | DAC | ADC/DAC SNR | ADC/DAC THD+N | Headphone driver | Sampling rate | ROM 16-Bits | ROM 4-Bits | I/O Port | Interrupt | LCD Mode | Oscillator | Current Operate | Current Halt | Current Stop | Sound Output | Application | Data download |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
CJC4354 | DAC | 3.0~3.6V | QFN4*4-28 | Stereo DAC with 24-Bit, 192 kHz Stereo D/A Converter and 3W Class AB Audio Power Amplifier | Handheld gaming/Mobile multimedia/ DVD players /Digital TVS | - | - | - | - | - | - | - | 96dB | -83dB | 16Ω /32Ω | 8~192kHz | - | - | - | - | - | - | - | - | - | - | - | Download |
CJC4334H | DAC | 3.0~3.6V | SOP8 | Stereo DAC with 24-Bit, 192 kHz Stereo D/A Converter | - | - | - | - | - | - | - | 2 | 92dB | -87dB | 16Ω /32Ω | 8~192kHz | - | - | - | - | - | - | - | - | - | - | - | Download |
CJC4344H | DAC | 3.0~3.6V | MSOP10 | Stereo DAC with 24-Bit, 192 kHz Stereo D/A Converter | Widely used in products such as handheld games, mobile multimedia, DVD players, and digital televisions | - | - | - | - | - | - | 2 | 97dB | -94dB | 16 Ω/32Ω | 8~192kHz | - | - | - | - | - | - | - | - | - | - | - | Download |
